Products Description

When it comes to waterproofing solutions, TPO waterproofing membrane is a versatile and cost-effective choice. It can be used for both exposed roofs and buried foundations. TPO stands for Thermoplastic Olefin, which is a type of polymer material known for its excellent flexibility, durability, and weather resistance.

Compared to other waterproofing materials, TPO waterproofing membrane has several advantages.

1. Cost-Effective: TPO waterproofing membrane offers excellent value for money. It is more affordable than EPDM and PVC membranes, especially when you factor in its long-term performance and energy efficiency benefits.
2. Flexible and Durable: TPO waterproofing membrane is highly flexible and can conform to any shape without cracking. It can also withstand extreme temperatures and weather conditions, ensuring long-lasting protection for your building.
3. Easy to Install: TPO waterproofing membrane is easy to install and can be heat-welded to create a seamless, watertight barrier. This reduces the risk of leaks and enhances the overall durability of the waterproofing system.
4. Environmentally Friendly: TPO waterproofing membrane is recyclable and can be reused after its lifetime. It is also energy efficient as it reflects heat, reducing the need for air conditioning and lowering your energy bills.

5. Excellent Aging Properties: TPO waterproofing membrane has excellent resistance to UV rays, chemical exposure, and weathering. This means it can maintain its performance and appearance over a long period of time, providing reliable protection against water damage.

Products Properties

We have developed a series of TPO waterproofing membrane product grades with a service life of 5-25 years.

9513MP(Service life 25 years)

GB 27789-2011
Testing items	Standard Requirements	Direction	Result
Mechanical Properties	Tensile strength ≥12Mpa	Horizontal	14.7
	Tensile strength ≥12Mpa	Vertical	18.9
	Elongation ≥500%	Horizontal	1130
	Elongation ≥500%	Vertical	769
	Right Angle Tear ≥260N/mm	Horizontal	74
	Right Angle Tear ≥260N/mm	Vertical	95
Heat aging	Tensile strength retention ≥90%	Horizontal	98
	Tensile strength retention ≥90%	Vertical	99
	Elongation retention ≥90	Horizontal	93
	Elongation retention ≥90	Vertical	92
Weld strength	≥ 4N/mm		6
Light aging	15000h without cracking and chalking
Other Properties
Melt index	5.5	5kg at 230°C
Hardness	38D
Density	0.895

9513MT (Service life 10 years)

GB 27789-2011
Testing items	Standard Requirements	Direction	Result
Mechanical Properties	Tensile strength ≥12Mpa	Horizontal	15
	Tensile strength ≥12Mpa	Vertical	20
	Elongation ≥500%	Horizontal	1530
	Elongation ≥500%	Vertical	848
	Right Angle Tear ≥260N/mm	Horizontal	81
	Right Angle Tear ≥260N/mm	Vertical	95
Heat aging	Tensile strength retention ≥90%	Horizontal	99.7
	Tensile strength retention ≥90%	Vertical	99.2
	Elongation retention ≥90	Horizontal	92.1
	Elongation retention ≥90	Vertical	97.2
Weld strength	≥ 4N/mm		8
Light aging	10000h without cracking and chalking
Other Properties
Melt index	6	5kg at 230°C
Hardness	40D
Density	0.930

9513M (Service life 10 years)

GB 27789-2011
Testing items	Standard Requirements	Direction	Result
Mechanical Properties	Tensile strength ≥12Mpa	Horizontal	14
	Tensile strength ≥12Mpa	Vertical	23
	Elongation ≥500%	Horizontal	1357
	Elongation ≥500%	Vertical	1687
	Right Angle Tear ≥260N/mm	Horizontal	80
	Right Angle Tear ≥260N/mm	Vertical	106
Heat aging	Tensile strength retention ≥90%	Horizontal	97
	Tensile strength retention ≥90%	Vertical	96
	Elongation retention ≥90	Horizontal	90
	Elongation retention ≥90	Vertical	93
Weld strength	≥ 4N/mm		8.6
Light aging	10000h without cracking and chalking
Other Properties
Melt index	5.5	5kg at 230°C
Hardness	48D
Density	0.990
